EFFECTS EDIT
S2000 Operator’s Manual - Version 1.30 Page 181
DELAY AND ECHO EFFECTS
The next section in the effects allows you to set delay and echo effects. The delay line in the
EB16 multi-effects is stereo allowing you to create ping pong and many other stereo delay
effects. It can also operate in a mono mode and this has the advantage of doubling the
available delay time.
This screen allows you to select the type of echo effect. The options are:
MONO LEFT This will create a mono echo effect and the signal is derived through the delay
line’s left input.
DELAY L
DELAY R
HF DAMP
FBK
LEFT IN
MONO L+R This creates mono echo and delay effects but derives its input signal from the
left and right inputs to the delay line.
DELAY L
DELAY R
HF DAMP
FBK
LEFT IN
RIGHT IN
NOTE: When using mono echo with the modulation effects, you will note that, depending on
the selection made (i.e. MONO LEFT ) you will only hear the effect from the left or right output
of the modulation effects. With some effects, this will hardly be noticeable but with the PITCH
SHIFT effect, you will only hear echo on one or other of the pitch shift channels. Similarly,
when using AUTOPAN, only one channel will be echoed. To apply echo to both channels of
the modulation effects, use the MONO L+R or STEREO selection.
