PROGRAM EDIT
S2000 Operator’s Manual - Version 1.30 Page 105
THE SECOND FILTERS
If the IB304F filter bank is installed in your S2000, the next group of pages gives access to the
second bank of filters and the third envelope generator Pressing PAGE DOWN or GROUP
DOWN from the ENV2 pages will display the following screen:
NOTE: If the IB304F is not installed, these pages will not appear.
The second filter offers four different types of filters: LOWPASS, BANDPASS and HIGHPASS
plus a special EQ filter selection.The lowpass filter we have already seen and offers this type of
response graph:
HARMONICS
CUTOFF FREQUENCYROLL-OFF SLOPE
L
E
V
E
L
FREQUENCY
Here, high frequency components above the cutoff frequency are removed and only lower
frequency components will pass through the filter. When the resonance control is increased,
the area around the cutoff frequency is boosted to give synthesiser effects.
The band pass selection offer this type of response slope:
HARMONICS
CUTOFF FREQUENCYROLL-OFF SLOPE
L
E
V
E
L
FREQUENCY
Here, frequencies below the cutoff and above are removed. You may simultaneously remove
depth and top end using this selection and the result is a buzzy, thinner type of sound. As the
resonance amount is increased, so the width of the response slope gets narrower so that
individual harmonics are emphasised.

Akai s2000 Specifications

General

Type	Sampler
Polyphony	32 voices
Sampling Frequency	44.1kHz
Filters	Digital low-pass filter
MIDI	In, Out, Thru
Bit Depth	16-bit
Memory	2 MB, expandable to 32 MB
Outputs	8 individual outputs, stereo master output
LFO	1 LFO
Display	LCD
Storage	3.5" Floppy Disk
Inputs	Stereo input
