Spectrum Analyzer Measurements 3-19 Coverage Mapping (Option 431)
Spectrum Analyzer MG PN: 10580-00447 Rev. H 3-93
1. The coverage mapping status panel provides quick access to common settings and allows you to start and stop
a coverage mapping measurement. A color-coded signal strength legend including the corresponding
percentage values are also displayed. See “STATUS PANEL (Coverage Mapping)” on page 3-96.
2. Select map zoom tool to increase (+) or decrease (-) zoom level. You can also drag the zoom level indicator up
or down, or you can pinch to change zoom level.
3. Tabular section displays the following three measurement sections:
• Current map measurement mode section includes the total number of points, average, minimum and
maximum values.
• Outdoor maps section lists a number of outdoor maps and an option to add more maps.
• Route replay section consists of current map mode, its value and quality. It also includes navigation controls
displayed as arrow heads to either move up/down single point or in increments of five.
4. The map display area shows map data for the current area and color-coded dots corresponding to the signal
colors that are set up for the recorded measurement data.
5. Map scale shows length for both imperial (miles) and metric (kilometers) units.
6. Re-centering tool centers the current location on the map.
7. Select SETUP menu to configure coverage mapping measurement settings. See “SETUP Menu (Coverage
Mapping)” on page 3-97.
8. Select pencil icon to edit or rename the saved name of the available map.
9. Select trash can icon to delete the unwanted map (s).
10.Select + ADD MORE MAPS to open “Map Tool” of Tools menu.
11.Select ROUTE REPLAY to replay the path traveled during coverage mapping.
12.Select + ADD MAPS to add more maps.
Figure 3-75. Coverage Mapping (Outdoor) (2 of 2)
