General Information 1-2 Instrument Description
MS2090A UG PN: 10580-00444 Rev. U 1-3
1-2 Instrument Description
The MS2090A Field Master Pro is a synthesizer-based handheld spectrum analyzer that provides quick and
accurate measurement results. The instrument is designed for monitoring, measuring, and analyzing signal
environments. Measurements can easily be made by using the main instrument functions: frequency, span,
amplitude, and bandwidth. A 10.1" capacitive touchscreen enables fast, easy data entry.
Typical measurements include in-band interference and transmit spectrum analysis, plus cell site and
802.11a/b/g interference testing. Options are available for RF, advanced demodulation, and over-the-air (OTA)
measurement. A full range of marker capabilities (such as peak, center, and delta functions) are provided for
faster, more comprehensive analysis of displayed signals. Upper and lower multi-segmented limit lines are
available to create quick, simple pass/fail measurements.
Time and date stamping of measurement data is automatic. The internal memory provides for the storage and
recall of up to 1000 measurement setups and up to 1000 traces. Measurements and setups can be stored
internally on the instrument or on a USB memory device for later recall.
Available Models
Table 1-2 lists the frequency options available with the MS2090A Field Master Pro.
Available Options
Available options for the Field Master Pro are listed in Table 1-3.
Note
Not all after-market USB drives are compatible with Field Master Pro. The USB drive must contain a
single partition using either FAT32, exFAT, NTFS and ext4 file formats.
Table 1-2. Field Master Pro Frequency Options
Model Frequency Range
MS2090A-0709 Signal Analyzer, 9 kHz to 9 GHz
MS2090A-0714 Signal Analyzer, 9 kHz to 14 GHz
MS2090A-0720 Signal Analyzer, 9 kHz to 20 GHz
MS2090A-0726 Signal Analyzer, 9 kHz to 26.5 GHz
MS2090A-0732 Signal Analyzer, 9 kHz to 32 GHz
MS2090A-0743 Signal Analyzer, 9 kHz to 43.5 GHz
MS2090A-0754 Signal Analyzer, 9 kHz to 54 GHz
Table 1-3. Available Options
Option
a
Description
MS2090A-0006 Remove Wi-Fi
MS2090A-0019* High Accuracy Power Meter (requires compatible USB power sensor, sold separately)
MS2090A-0024* Interference Finder
MS2090A-0031* GNSS Receiver (requires external GPS antenna)
MS2090A-0089* Zero Span IF Output
MS2090A-0090* Gated Sweep
MS2090A-0103* 55 MHz Analysis Bandwidth
MS2090A-0104* 110 MHz Analysis Bandwidth
MS2090A-0124* IQ Waveform Capture
MS2090A-0125* IQ Waveform Streaming (requires Option 124)
MS2090A-0126* IQ Waveform Capture (non-export control)
MS2090A-0127* IQ Waveform Streaming (non-export control, requires Option 126)
MS2090A-0128* Vector Signal Analysis Enabled (requires Option 124 or 126; use with MX280005A)
MS2090A-0199* Real-Time Spectrum Analyzer
