Spectrum Analyzer Measurements 3-12 Setting Up Advanced Measurements
Spectrum Analyzer MG PN: 10580-00447 Rev. H 3-61
MEASURE Menu (Zero Span)
Burst Average Power
Burst Average Power is the average power measured between two user defined markers positioned in the time
domain.
.
MEASUREMENT: Selects either zero span or burst power measurement.
SETUP: Opens “SETUP Menu” on page 3-62.
Figure 3-47. MEASURE Menu (Zero Span)
1. Status Panel: The status panel provides quick access to common spectrum analyzer settings.
2. Setup Menu: All burst average power measurement parameters are set via the SETUP menu
3. Burst Power Table: This table shows the values of burst average power, start and stop times.
Figure 3-48. Burst Average Power Measurement
