Spectrum Analyzer Measurements 3-22 Carrier-to-Interference
Spectrum Analyzer MG PN: 10580-00447 Rev. H 3-117
LIMITS Menu
C/I LIMIT: Sets the carrier-to-interference ratio limit in dB. Enter the desired C/I ratio (dB)
limit value using the numeric keypad.
POWER LIMIT: Sets the desired value of the carrier power limit. Enter the desired carrier
power (dBm) limit value using the numeric keypad.
I LIMIT: Sets the desired value of the interference power limit. Enter the desired
interference power (dBm) limit value using the numeric keypad
Figure 3-97. SETUP Menu (C/I Measurement)
