3-16 Spectrum Emission Mask Spectrum Analyzer Measurements
3-78 PN: 10580-00447 Rev. H Spectrum Analyzer MG
1. The status panel provides quick access to common spectrum analyzer settings. See “STATUS PANEL (SEM)”
on page 3-80.
2. SEM Mask
3. Spectrum Emission
4. SEM Mask
5. All SEM measurement parameters are set via the SETUP menu. See “SETUP Menu (SEM)” on page 3-81.
Figure 3-65. SEM Measurement
