ML248xA / ML249xA CW Setup and Measurement

7-2 13000-00162

September 2005

3. Set up averaging

Press the Channel hard key followed by the Averaging soft key. The averaging

setting should be set to Auto by default and this setting is suitable for CW

measurement. Averaging can also be set to either Moving or Repeat and the

difference between these settings is explained in the section on common procedures.

4. Connect the RF port on the sensor to the DUT and monitor the measurement results

on the screen.
