ML248xA / ML249xA Terminology Glossary

E-2 13000-00162

September 2005

Term Meaning

Ind Indicator

Lim Limit

Lvl Level

Max Maximum

Meas Measurement

Min Minimum

Mkr Marker

Num Number

PDF Probability Density Function

Pk Peak

Pos Position

POST Power On Self-Test

Pwr Power

Ref Reference

Rel Relative

Res Resolution

RRS Random repetitive sampling

RS232C Recommended standard-232C

Sngl Single

Spec Specification

TTL Transistor-Transistor Logic

USB Universal Serial Bus,

Vltg Voltage

WCDMA Wideband CDMA

WLAN Wireless Local-Area Network
