Anritsu ML2480B Series User Manual

ML248xA / ML249xA Common Procedures
5-4 13000-00162
September 2005
Procedure Key combination Page
Limits – holding the display of
the limit fail indicator
Channel Æ More Æ Limit
Checking Æ Fail Hold
5-66
Limits – recalling complex limits Channel Æ More Æ Limit
Checking Æ Set Up Æ
Select from soft keys
5-63
Limits – repeating limits Channel Æ More Æ Limit
Checking Æ Set Up Æ
Repeat Limit
5-65
Limits - set up complex limits Channel Æ More Æ Limit
Checking Æ Set Up
5-61
Limits - set up simple limits Channel Æ More Æ Limit
Checking Æ Set Up
5-60
Limits - sound an alarm if the
results of measurement go
outside the specified limits.
Channel Æ More Æ Limit
Checking Æ Audible
Alarm
5-66
Marker – display active Channel Æ Markers Æ
Active Marker
5-49
Marker - move active marker to
the maximum point on the trace.
Channel Æ Markers Æ
Marker Functions Æ
Active to Max
5-52
Marker - move active marker to
the minimum point on the trace.
Channel Æ Markers Æ
Marker Functions Æ
Active to Min
5-52
Marker – position active Channel Æ Markers Æ
Position Act Mkr Æ Enter
value.
5-49
Marker – select active Channel Æ Markers Æ
Assign Act Mkr Æ Select
from soft keys.
5-49
Markers - enable for display. Channel Æ Markers Æ
Set Up Markers Æ Select
marker Æ Display Marker
5-47
Markers - set the target levels
for the pulse rise and fall time
searches
Channel Æ Markers Æ
Marker Functions Æ
Advanced Functions Æ
Search Set Up
5-58
Markers - set up Channel Æ Markers Æ
Set Up Markers Æ Select
marker Æ Enter value.
5-47
Markers - turn all off. Channel Æ Markers Æ
Set Up Markers Æ All
Mkrs Off
5-48
