Chapter 3 Measurement
3-14
3.5 Changing Wavelength and Resolution
This section explains how to change the wavelength and resolution on the
horizontal axis of the screen.
3.5.1 Changing Wavelength
To change the screen center wavelength
1. Press
Center
.
2. Enter the center wavelength using the rotary knob or keypad. The
input setting range is from 600 to 1750 nm.
To set the wavelength with the maximum level at the screen center:
1. Press
Center
.
To change the range of the screen width:
1. Press
Span
.
2. Input the value using
f1
though
f7
, rotary knob, or keypad. The input
setting range is 0 and from 0.2 to 1200 nm.
3.5.2 Changing Resolution
1. Press
Res
.
2. Enter the resolution using
f1
through
f5
.
