Chapter 5 Measurement Functions
5-24
5.5.3 How to Set the Noise Measurement Method
In the Noise Parameter dialog box, set the noise level for the SNR
measurement and display/detection method.
Figure 5.5.3-1 Noise Parameter Dialog Box
Table 5.5.3-1 Setting Range of the Parameters in the Noise Parameter
Dialog Box
Item Min. Max. Unit
Fitting Span
0.01
20.00
nm
Masked Span
0.01
20.00
nm
Noise BW
0.1
1.0
nm
Noise Position
0.01
100.00
nm
Span
0.01
100.00
nm
