Chapter 2 Before Use
2-2
2.1 Unpacking and Installation
2.1.1 Unpacking
Table 2.1.1-1 lists the standard configurations of the MS9740B. At
unpacking, check that all items are included. Contact your Anritsu
Service and Sales Office or agent if any parts are missing or damaged.
Table 2.1.1-1 Standard Configurations
Item Model Product Name Q'ty Remarks
Main unit
MS9740B
Optical Spectrum Analyzer
1
Accessories
Z2024A
Power Cord (2.6 m)
MS9740B Operation Manual (CD)*
TAA-1CT140003 Microsoft
Software License Terms (WES7)
1
1
1
Packed in
Accessory
Box
*: The CD includes two MS9740B Optical Spectrum Analyzer
Operation Manuals: Mainframe and Remote Control.
Options for the MS9740B listed in Table 2.1.1-2 are provided. Select one,
as you need. The MS9740B might be returned to Anritsu Service and
Sales Office for installing some options. For the specifications, refer to
Appendix A “Specifications”.
Table 2.1.1-2 Options
Model Name Remarks
MS9740B-001
MS9740B-101*
1
MS9740B-201*
2
GPIB Interface
Interface used at remote control
Controls MS9740B via GPIB
connector on rear-panel
MS9740B-002
MS9740B-102*
1
MS9740B-202*
2
Light Source for
Waveform Calibration
Light source for wavelength
calibration
Calibrates wavelength to within
±20 pm
MS9740B-108*
1
MS9740B-208*
2
OS Upgrade to Win10
Retrofit
Options to upgrade the OS from
Windows Embedded Standard 7 to
Windows 10 IoT
MS9740B-037
MS9740B-038
MS9740B-039
MS9740B-040
FC
ST
DIN
SC
Standard option 037
All available as PC types
(spherical polishing)
*1: Must be returned to Anritsu (Japan) when installing.
*2: Must be returned to an Anritsu Service office when installing.
The option number of the added option is indicated on the label on the
rear panel.
