Anritsu MS9740B - Appendix B Initial Values

B-1
Appendix B
Appendix B Initial Values
Table B-1 Wavelength
Item Initial value
Center
1350.00 nm
Span
500.0 nm
Start
1100.00 nm
Stop
1600.00 nm
Mkr Value Wl/Freq
Wl
Value in Air/Vacuum
Vacuum
Table B-2 Level Scale
Item Initial value
Scale Select
Log
Log (/div.)
10.0 dB/div.
Reference Level
20.0 dBm
Linear Scale
100.0 mW
Optical Att.
Off
Table B-3 Res/VBW/Avg
Item Initial value
Res
1.0 nm
VBW
1 kHz
Point Average
Off
Sweep Average
1
Smooth
Off
Sampling Points
501 pt
Actual Res
Off
Table B-4 Peak/Dip Search
Item Initial value
Status
Off
Search Threshold
Auto/Manual
Auto
Peak to Peak Calculation
On/Off
Off
Search Threshold
0.10 dB
