Appendix B Initial Values
B-2
Table B-5 Analysis
Item Initial value
Status
Off
Threshold
Cut Lvl: 3.0 dB
ndB Loss
ndB: 3.0 dB
SMSR
Side mode: 2nd Peak
Envelope
Cut Lvl: 3.0 dB
RMS
Kσ: 2.35 σ
S-Level: 20.0 dB
Table B-6 Trace
Item Initial value
Active Trace
A
Trace Type
Trace A: Write
Trace B-J: Blank
Storage Mode
Off
Calculation
Trace A = B – C
Trace B = C – D
Trace C = D – E
Trace D = E – F
Trace E = F – G
Trace F = G – H
Trace G = H – I
Trace H = I – J
Trace I = J – A
Trace J = A – B
Display On/Off
On
Graph
Normal
