Chapter 2 Before Use
2-6
When using the optical input/output connector, open the optical connector
cover as shown.
Figure 2.2.1-2 How to Opening the Optical Connector Cover
2.2.2 Rear Panel
Figure 2.2.2-1 Rear Panel
Inlet
Serial
USB
GPIB
Trigger input
Mic input
Line output
Ethernet
Line input
Monitor output
Not used
Serial Number,
Option Number Label
