4.6 Changing Waveform Memory Settings and Calculation between Memories
4-23
4
Changing Measurement Conditions
Figure 4.6-2 Trace Setting Flowchart
Select Active Trace.
Set Trace Type.
Trace Type=Write
Yes
No
Set Storage Mode.
Trace Type=
Calculation
Yes
No
Set Calculation Formula.
Set Display On/Off.
Set Absolute/Relative Display
Method.
Start
End
