Appendix B Initial Values
B-6
Table B-13 Application - Opt .AMP Test
Item Initial value
Method
Spect Div On
Write to Pin/Pout
Pin
Pin
A
Pout
B
Pase
C
NF Select
S-ASE
ASE Fitting
Gauss Fit
Fitting Span
5.00 nm
Masked Span
2.00 nm
Pin Loss
0.00 dB
Test Pout Loss
0.00 dB
NF Calibration
1.000
O.BPF Level Calibration
0.00 dB
O.BPF Band Width
3.00 nm
Pol Loss
0.00 dB
