Chapter 1 Outline
1-12
Figure 1.3-7 Measurement Example of Resolution 1.0 nm
Remote Control
This is a function for sending commands from a PC to the MS9740B via
the Ethernet or GPIB (Option) interface to change the measurement
conditions and to send the measurement results from the MS9740B to the
PC. Refer to
MS9740B Optical Spectrum Analyzer Remote Control
Operation Manual
for details of the remote control function.
Monochrometer
This is a device for splitting the light into each wavelength. The MS9740B
uses a diffraction grating as a device to split light.
1550 nm 0.2 nm/Div 1551 nm In Air 1552 nm
0
100
µ
W
50
µ
W
Res 1.0 nm
REF
Half width 0.102 nm
Setting resolution
