2.12 Screen Names
2-47
2
Before Use
Figure 2.12-3 Marker, Level Scale, Wavelength Displays
Figure 2.12-4 Measurement Condition Setting Display Field
Figure 2.12-5 Trace Display
Level
scale
Reference level
Wavelength
scale
Start
wavelength
Wavelength in air
/ Wavelength in
vacuum
Center
wavelength
Stop
wavelength
Value of wavelength marker
Wavelength marker
wavelength difference
Trace marker/Delta marker value
Level Marker Value
Level Marker
Level Difference
Resolution
Measurement
point count
Sweep averaging count
Point averaging count
Smoothing point
count
VBW
Meas Time
Interval
High Dynamic Range Mode
External
trigger
Actual
resolution
Trace name
A
Wri Max
Trace type
Active trace display
Storage Mode or
Calculating formula
