User's Manual 752 Document #: LTRT-10532
Mediant 500L Gateway & E-SBC
♦ Manipulation Set ID: 2
♦ Action Subject: header.contact.url.ac-int
♦ Action Type: Modify
♦ Action Value: '2'
4. In the SIP Interfaces table, configure the following SIP Interfaces:
• Index 0 (SIP Interface for IP Phone A):
♦ Name: Interface-1
♦ UDP Port: 5060
♦ Pre-classification Manipulation Set ID: 1
• Index 1 (SIP Interface for IP Phone B):
♦ Name: Interface-2
♦ UDP Port: 5080
♦ Pre-classification Manipulation Set ID: 2
5. In the Proxy Sets table, configure a Proxy Set for each proxy server (primary and
secondary):
• Index 0:
♦ Proxy Name: Primary
♦ SBC IPv4 SIP Interface: Interface-1
♦ Proxy Address: 200.10.10.1
• Index 1:
♦ Proxy Name: Secondary
♦ SBC IPv4 SIP Interface: Interface-2
♦ Proxy Address: 200.10.10.2
6. In the IP Groups table, configure the following IP Groups:
• Index 0:
♦ Type: Server
♦ Name: Primary-Proxy
♦ Proxy Set: Primary
♦ Classify By Proxy Set: Enable
• Index 1:
♦ Type: Server
♦ Name: Sec-Proxy
♦ Proxy Set: Secondary
♦ Classify By Proxy Set: Enable
• Index 2:
♦ Type: User
♦ Name: IP-Phone-A
• Index 3:
♦ Type: User
♦ Name: IP-Phone-B
7. In the Classification table, configure rules to classify calls from the IP Phones based
on SIP Interface:
• Index 0:
♦ Source SIP Interface: Interface-1
♦ Source IP Group: IP-Phone-A
• Index 1:
