User's Manual 960 Document #: LTRT-10532
Mediant 500L Gateway & E-SBC
Message Item Description
<-- DIGIT(0) Ch:0 OnTime:0 InterTime:100
Direction:0 System:1 [File: Line:-1]
18:38:14. 83 : 10.33.45.72 : NOTICE:
[S=236][SID:2ed1c8:96:5] (lgr_flow)(620)
#0:DIGIT_EV [File: Line:-1]
18:38:14. 83 : 10.33.45.72 : NOTICE:
[S=237][SID:2ed1c8:96:5] (lgr_flow)(621) |
#0:DIGIT_EV [File: Line:-1]
18:38:14.958 : 10.33.45.72 : NOTICE:
[S=301][SID:2ed1c8:96:5] (lgr_flow)(625) |
#0:DIGIT_EV [File: Line:-1]
You can disable the inclusion of the message sequence number in
Syslog messages, by setting the 'CDR Syslog Sequence Number'
parameter to Disable (see ''Configuring Syslog'' on page 964).
Log Number
(lgr)(number)
Ignore this number; it has been replaced by the Message Sequence
Number (described previously).
Session ID (SID)
Unique SIP call session and device identifier. The device identifier
facilitates debugging by clearly identifying the specific device that
sent the log message, especially useful in deployments consisting of
multiple devices. In addition, the benefit of unique numbering is that
it enables you to filter the information (such as SIP, Syslog, and
media) according to device or session ID.
The syntax of the session and device identifiers are as follows:
[SID=<last 6 characters of device's MAC address>:<number of times
device has reset>:<unique SID counter indicating the call session;
increments consecutively for each new session; resets to 1 after a
device reset>]
For example:
14:32:52.028: 10.33.8.70: NOTICE: [S=9369]
[SID=2ed1c8:96:5] (lgr_psbrdex)(274) recv <--
OFF_HOOK Ch:4
Where:
 2ed1c8 is the device's MAC address.
 96 is the number of times the device has reset.
 5 is a unique SID session number (in other words, this is the fifth
call session since the last device reset).

Gateway application: A call session is considered either as a
Tel-to-IP leg or an IP-to-Tel leg, where each leg is assigned a
unique session number.

SBC application: A session includes both the outgoing and
incoming legs, where both legs share the same session
number.

Forked legs and alternative legs share the same session
number.
Board ID (BID)
Unique non-SIP session related (e.g., device reset or a Trunk alarm)
and device identifier. The device identifier facilitates debugging by
clearly identifying the specific device that sent the log message,
especially useful in deployments consisting of multiple devices. In
addition, the benefit of unique numbering is that it enables you to
filter the information according to device.
The syntax of the BID is as follows:
