Chapter 5. Functions

Operation type
The operation type can be set for internal events.
Item (bank) Display Description Initial value User level
Internal event 1 configuration 1
Operation type
(event configuration bank)
E1.C1
0: No event
1: PV high limit
2: PV low limit
3: PV high and low limits
4: Deviation high limit
5: Deviation low limit
6: Deviation high and low limits
7: Deviation high limit (final SP reference)
8: Deviation low limit (final SP reference)
9: Deviation high and low limits (final SP
reference)
10: SP high limit
11: SP low limit
12: SP high and low limits
13: MV high limit
14: MV low limit
15: MV high and low limits
16: Heater 1 burnout/overcurrent
17: Heater1 short circuit
18: Heater 2 burnout/overcurrent
19: Heater 2 short circuit
20: Loop diagnosis 1
21: Loop diagnosis 2
22: Loop diagnosis 3
23: Alarm (status)
24: READY (status)
25: MANUAL (status)
26: Invalid
27: AT in execution (status)
28: During SP ramp (status)
29: Control direct action (status)
30: Invalid
31: Invalid
32: Timer (status)
33: Invalid
0 Simple,
standard,
advanced
Internal event 2 configuration 1
Operation type
(Event configuration bank)
E2.C1
0
Internal event 3 configuration 1
Operation type
(event configuration bank)
E3.C1
0
Internal event 4 configuration 1
Operation type
(event configuration bank)
E4.C1
0
Internal event 5 configuration 1
Operation type
(event configuration bank)
E5.C1
0
