Chapter 10. List of Communication Data
Bank Item RAM address EEPROM address RAM
EEPROM Decimal
point
Notes
Decimal Hexa-
decimal
Decimal Hexa-
decimal
Read Write Read Write
Setup PV Decimal point position 5204 1454 21588 5454
 
−
PV range low limit 5205 1455 21589 5455
 
P
PV range high limit 5206 1456 21590 5456
 
P
SP low limit 5207 1457 21591 5457 P
SP high limit 5208 1458 21592 5458 P
PV square root extraction dropout 5209 1459 21593 5459
 
1
(Reserved for future use.) 5210 145A 21594 545A




−
(Reserved for future use.) 5211 145B 21595 545B




P
(Reserved for future use.) 5212 145C 21596 545C




P
(Reserved for future use.) 5213 145D 21597 545D




−
Control action (direct/reverse) 5214 145E 21598 545E −
Output operation at PV alarm 5215 145F 21599 545F −
Output at PV alarm 5216 1460 21600 5460 1
Output at READY (Heat) 5217 1461 21601 5461 1
Output at READY (Cool) 5218 1462 21602 5462 1
Output operation at changing AUTO/
MANUAL
5219 1463 21603 5463 −
Preset MANUAL value 5220 1464 21604 5464 1
Initial output type (mode) of PID control 5221 1465 21605 5465 −
Initial output of PID control 5222 1466 21606 5466 1
Integral time and derivative time deci-
mal point position
5223 1467 21607 5467
−
(Reserved for future use.) 5224 1468 21608 5468




−
(Reserved for future use.) 5225 1469 21609 5469




−
Heat/cool control 5226 146A 21610 546A −
(Reserved for future use.) 5227 146B 21611 546B




−
Heat/Cool control dead zone 5228 146C 21612 546C 1
(Reserved for future use.) 5229 146D 21613 546D




1
LSP system group 5230 146E 21614 546E −
SP ramp type 5231 146F 21615 546F




−
SP ramp unit 5232 1470 21616 5470 −
STEP time unit 5233 1471 21617 5471
−
STEP PV start 5234 1472 21618 5472 −
STEP loop 5235 1473 21619 5473 −
CT1 operation type 5236 1474 21620 5474 −
CT1 output 5237 1475 21621 5475 −
CT1 measurement wait time 5238 1476 21622 5476 −
CT2 operation type 5239 1477 21623 5477 −
CT2 output 5240 1478 21624 5478 −
CT2 measurement wait time 5241 1479 21625 5479 −
Control output 1 range 5242 147A 21626 547A −
Control output 1 type 5243 147B 21627 547B −
Control output 1 scaling low limit 5244 147C 21628 547C S
Control output 1 scaling high limit 5245 147D 21629 547D S
Control output 1 MV scaling width 5246 147E 21630 547E P
Control output 2 range 5247 147F 21631 547F −
Control output 2 type 5248 1480 21632 5480 −
Control output 2 scaling low limit 5249 1481 21633 5481 S
Control output 2 scaling high limit 5250 1482 21634 5482 S
