Chapter 10. List of Communication Data
Bank Item RAM address EEPROM address RAM
EEPROM Decimal
point
Notes
Decimal Hexa-
decimal
Decimal Hexa-
decimal
Read Write Read Write
Setup Control output 2 MV scaling width 5251 1483 21635 5483 P
(Reserved for future use.) 5252 1484 21636 5484




−
(Reserved for future use.) 5253 1485 21637 5485




−
(Reserved for future use.) 5254 1486 21638 5486




S
(Reserved for future use.) 5255 1487 21639 5487




S
(Reserved for future use.) 5256 1488 21640 5488




−
(Reserved for future use.) 5257 1489 21641 5489




−
(Reserved for future use.) 5258 148A 21642 548A




1
(Reserved for future use.) 5259 148B 21643 548B




−
(Reserved for future use.) 5260 148C 21644 548C




−
(Reserved for future use.) 5261 148D 21645 548D




−
(Reserved for future use.) 5262 148E 21646 548E




−
(Reserved for future use.) 5263 148F 21647 548F




1
Communications type 5264 1490 21648 5490
 
−
Station address 5265 1491 21649 5491
 
−
Transmission speed (bps) 5266 1492 21650 5492
 
−
Data format (data length) 5267 1493 21651 5493
 
−
Data format (parity) 5268 1494 21652 5494
 
−
Data format (stop bit) 5269 1495 21653 5495
 
−
Communication minimum response
time
5270 1496 21654 5496
 
−
Key operation mode 5271 1497 21655 5497 −
[MODE] key function 5272 1498 21656 5498 −
Mode display setup 5273 1499 21657 5499 −
PV/SP display setup 5274 149A 21658 549A −
MV display setup 5275 149B 21659 549B −
EV display setup 5276 149C 21660 549C −
Event remaining time display setup 5277 149D 21661 549D −
CT input current display setup 5278 149E 21662 549E −
User level 5279 149F 21663 549F −
Status indicator 5280 14A0 21664 54A0 −
(Reserved for future use.) 5281 14A1 21665 54A1
   
−
(Reserved for future use.) 5282 14A2 21666 54A2
   
−
(Reserved for future use.) 5283 14A3 21667 54A3
   
−
(Reserved for future use.) 5284 14A4 21668 54A4
   
−
(Reserved for future use.) 5285 14A5 21669 54A5
   
−
(Reserved for future use.) 5286 14A6 21670 54A6
   
−
(Reserved for future use.) 5287 14A7 21671 54A7
   
−
(Reserved for future use.) 5288 14A8 21672 54A8
  

−
(Reserved for future use.) 5289 14A9 21673 54A9




−
Number of CT1 turns 5290 14AA 21674 54AA −
Number of CT1 power wire loops 5291 14AB 21675 54AB −
Number of CT2 turns 5292 14AC 21676 54AC −
Number of CT2 power wire loops 5293 14AD 21677 54AD −
PV input failure (under range) type 5297 14B1 21681 54B1 −
Sampling cycle 5298 14B2 21682 54B2 −
