10-5
Chapter 10. List of Communication Data
Bank Item RAM address EEPROM address RAM EEPROM Decimal
point
Notes
Decimal Hexa-
decimal
Decimal Hexa-
decimal
Read Write Read Write
DI assign-
ment
Internal contact 1 operation type 5401 1519 21785 5519 −
Internal contact 1 input bit function 5402 151A 21786 551A −
Internal contact 1 input assignment A 5403 151B 21787 551B −
Internal contact 1 input assignment B 5404 151C 21788 551C −
Internal contact 1 input assignment C 5405 151D 21789 551D −
Internal contact 1 input assignment D 5406 151E 21790 551E −
Internal contact 1 polarity A 5407 151F 21791 551F −
Internal contact 1 polarity B 5408 1520 21792 5520 −
Internal contact 1 polarity C 5409 1521 21793 5521 −
Internal contact 1 polarity D 5410 1522 21794 5522 −
Internal contact 1 polarity 5411 1523 21795 5523 −
Internal contact 1 internal event No.
assignment
5412 1524 21796 5524 −
Internal contact 2 operation type 5413 1525 21797 5525 −
Internal contact 2 input bit function 5414 1526 21798 5526 −
Internal contact 2 input assignment A 5415 1527 21799 5527 −
Internal contact 2 input assignment B 5416 1528 21800 5528 −
Internal contact 2 input assignment C 5417 1529 21801 5529 −
Internal contact 2 input assignment D 5418 152A 21802 552A −
Internal contact 2 polarity A 5419 152B 21803 552B −
Internal contact 2 polarity B 5420 152C 21804 552C −
Internal contact 2 polarity C 5421 152D 21805 552D −
Internal contact 2 polarity D 5422 152E 21806 552E −
Internal contact 2 polarity 5423 152F 21807 552F −
Internal contact 2 internal event No.
assignment
5424 1530 21808 5530 −
Internal contact 3 operation type 5425 1531 21809 5531 −
Internal contact 3 input bit function 5426 1532 21810 5532 −
Internal contact 3 input assignment A 5427 1533 21811 5533 −
Internal contact 3 input assignment B 5428 1534 21812 5534 −
Internal contact 3 input assignment C 5429 1535 21813 5535 −
Internal contact 3 input assignment D 5430 1536 21814 5536 −
Internal contact 3 polarity A 5431 1537 21815 5537 −
Internal contact 3 polarity B 5432 1538 21816 5538 −
Internal contact 3 polarity C 5433 1539 21817 5539 −
Internal contact 3 polarity D 5434 153A 21818 553A −
Internal contact 3 polarity 5435 153B 21819 553B −
Internal contact 3 internal event No.
assignment
5436 153C 21820 553C −
Internal contact 4 operation type 5437 153D 21821 553D −
Internal contact 4 input bit function 5438 153E 21822 553E −
Internal contact 4 input assignment A 5439 153F 21823 553F −
Internal contact 4 input assignment B 5440 1540 21824 5540 −
Internal contact 4 input assignment C 5441 1541 21825 5541 −
Internal contact 4 input assignment D 5442 1542 21826 5542 −
Internal contact 4 polarity A 5443 1543 21827 5543 −
Internal contact 4 polarity B 5444 1544 21828 5544 −
Internal contact 4 polarity C 5445 1545 21829 5545 −
Internal contact 4 polarity D 5446 1546 21830 5546 −
Internal contact 4 polarity 5447 1547 21831 5547 −
Internal contact 4 internal event No.
assignment
5448 1548 21832 5548 −
Internal contact 5 operation type 5449 1549 21833 5549 −
Internal contact 5 input bit function 5450 154A 21834 554A −
