10-6
Chapter 10. List of Communication Data
Bank Item RAM address EEPROM address RAM EEPROM Decimal
point
Notes
Decimal Hexa-
decimal
Decimal Hexa-
decimal
Read Write Read Write
DI assign-
ment
Internal contact 5 input assignment A 5451 154B 21835 554B −
Internal contact 5 input assignment B 5452 154C 21836 554C −
Internal contact 5 input assignment C 5453 154D 21837 554D −
Internal contact 5 input assignment D 5454 154E 21838 554E −
Internal contact 5 polarity A 5455 154F 21839 554F −
Internal contact 5 polarity B 5456 1550 21840 5550 −
Internal contact 5 polarity C 5457 1551 21841 5551 −
Internal contact 5 polarity D 5458 1552 21842 5552 −
Internal contact 5 polarity 5459 1553 21843 5553 −
Internal contact 5 internal event No.
assignment
5460 1554 21844 5554 −
DO assign-
ment
Control output 1 operation type 5601 15E1 21985 55E1 −
Control output 1 output assignment A 5602 15E2 21986 55E2 −
Control output 1 output assignment B 5603 15E3 21987 55E3 −
Control output 1 output assignment C 5604 15E4 21988 55E4 −
Control output 1 output assignment D 5605 15E5 21989 55E5 −
Control output 1 polarity A 5606 15E6 21990 55E6 −
Control output 1 polarity B 5607 15E7 21991 55E7 −
Control output 1 polarity C 5608 15E8 21992 55E8 −
Control output 1 polarity D 5609 15E9 21993 55E9 −
Control output 1 polarity 5610 15EA 21994 55EA −
Control output 1 latch 5611 15EB 21995 55EB −
Control output 2 operation type 5612 15EC 21996 55EC −
Control output 2 output assignment A 5613 15ED 21997 55ED −
