10-16
Chapter 10. List of Communication Data
Bank Item RAM address EEPROM address RAM EEPROM Decimal
point
Notes
Decimal Hexa-
decimal
Decimal Hexa-
decimal
Read Write Read Write
PID (Reserved for future use.) 12351 303F 28735 703F
   
1
Cool-side MV low limit 3 12352 3040 28736 7040 1
Cool-side MV high limit 3 12353 3041 28737 7041 1
Proportional band 4 12306 3012 28690 7012 1
Integral time 4 12307 3013 28691 7013 C
Derivative time 4 12308 3014 28692 7014 C
Manual reset 4 12309 3015 28693 7015 1
MV low limit 4 12310 3016 28694 7016 1
MV high limit 4 12311 3017 28695 7017 1
Cool-side proportional band 4 12354 3042 28738 7042 1
Cool-side integration time 4 12355 3043 28739 7043 C
Cool-side derivative time 4 12356 3044 28740 7044 C
(Reserved for future use.) 12357 3045 28741 7045
   
1
Cool-side MV low limit 4 12358 3046 28742 7046 1
Cool-side MV high limit 4 12359 3047 28743 7047 1
Proportional band 5 12312 3018 28696 7018 1
Integral time 5 12313 3019 28697 7019 C
Derivative time 5 12314 301A 28698 701A C
Manual reset 5 12315 301B 28699 701B 1
MV low limit 5 12316 301C 28700 701C 1
MV high limit 5 12317 301D 28701 701D 1
Cool-side proportional band 5 12360 3048 28744 7048 1
Cool-side integration time 5 12361 3049 28745 7049 C
Cool-side derivative time 5 12362 304A 28746 704A C
(Reserved for future use.) 12363 304B 28747 704B
   
1
Cool-side MV low limit 5 12364 304C 28748 704C 1
Cool-side MV high limit 5 12365 304D 28749 704D 1
Proportional band 6 12318 301E 28702 701E 1
Integral time 6 12319 301F 28703 701F C
Derivative time 6 12320 3020 28704 7020 C
Manual reset 6 12321 3021 28705 7021 1
MV low limit 6 12322 3022 28706 7022 1
MV high limit 6 12323 3023 28707 7023 1
Cool-side proportional band 6 12366 304E 28750 704E 1
Cool-side integration time 6 12367 304F 28751 704F C
Cool-side derivative time 6 12368 3050 28752 7050 C
(Reserved for future use.) 12369 3051 28753 7051
   
1
Cool-side MV low limit 6 12370 3052 28754 7052 1
Cool-side MV high limit 6 12371 3053 28755 7053 1
Proportional band 7 12324 3024 28708 7024 1
Integration time 7 12325 3025 28709 7025 C
Derivative time 7 12326 3026 28710 7026 C
Manual reset 7 12327 3027 28711 7027 1
MV low limit 7 12328 3028 28712 7028 1
MV high limit 7 12329 3029 28713 7029 1
