10-17
Chapter 10. List of Communication Data
Bank Item RAM address EEPROM address RAM EEPROM Decimal
point
Notes
Decimal Hexa-
decimal
Decimal Hexa-
decimal
Read Write Read Write
PID
Cool-side proportional band 7 12372 3054 28756 7054 1
Cool-side integration time 7 12373 3055 28757 7055 C
Cool-side derivative time 7 12374 3056 28758 7056 C
(Reserved for future use.) 12375 3057 28759 7057
1
Cool-side MV low limit 7 12376 3058 28760 7058 1
Cool-side MV high limit 7 12377 3059 28761 7059 1
Proportional band 8 12330 302A 28714 702A 1
Integration time 8 12331 302B 28715 702B C
Derivative time 8 12332 302C 28716 702C C
Manual reset 8 12333 302D 28717 702D 1
MV low limit 8 12334 302E 28718 702E 1
MV high limit 8 12335 302F 28719 702F 1
Cool-side proportional band 8 12378 305A 28762 705A 1
Cool-side integration time 8 12379 305B 28763 705B C
Cool-side derivative time 8 12380 305C 28764 705C C
(Reserved for future use.) 12381 305D 28765 705D
1
Cool-side MV low limit 8 12382 305E 28766 705E 1
Cool-side MV high limit 8 12383 305F 28767 705F 1
Event Internal event 1 main setting 13056 3300 29440 7300 S
Internal event 1 sub-setting 13057 3301 29441 7301 S
Internal event 2 main setting 13058 3302 29442 7302 S
Internal event 2 sub-setting 13059 3303 29443 7303 S
Internal event 3 main setting 13060 3304 29444 7304 S
Internal event 3 sub-setting 13061 3305 29445 7305 S
Internal event 4 main setting 13062 3306 29446 7306 S
Internal event 4 sub-setting 13063 3307 29447 7307 S
Internal event 5 main setting 13064 3308 29448 7308 S
Internal event 5 sub-setting 13065 3309 29449 7309 S
LSP LSP1 13312 3400 29696 7400 P
LSP2 13313 3401 29697 7401 P
LSP3 13314 3402 29698 7402 P
LSP4 13315 3403 29699 7403 P
LSP5 13316 3404 29700 7404 P
LSP6 13317 3405 29701 7405 P
LSP7 13318 3406 29702 7406 P
LSP8 13319 3407 29703 7407 P
Instru-
ment
status 1
Representative alarm 14336 3800 30720 7800
− Bit 0: PV error
Bit 1: Undefined
Bit 2: CT error (AL11)
Bits 3–7: Undefined
Bit 8:
Initialization error
(AL80/83/84)
Bits 9–11: Undefined
Bit 12:
A/D conversion error
(AL70)
Bit 13:
Setting value error
(AL81/95)
Bit 14:
Adjustment value error
(AL82/96)
Bit 15: Undefined
DO state 14337 3801 30721 7801
− Same as RAM address 9205
(decimal).
DI state 14338 3802 30722 7802
− Same as RAM address 9206
(decimal).
