14-3
Chapter 14. Specifications
z
Control output (selectable by model No.)
Item Description
Relay output
Contact configuration 1c (SPDT)
Contact rating 250 V AC / 30 V DC, 3 A (resistive load)
Service life N.O. side: 100,000 cycles or more
N.C. side: 100,000 cycles or more
Minimum switching
specifications (reference
value)
5 V, 100 mA
Minimum open/close time 50 ms
Voltage pulse output (for SSR drive)
Voltage when open 19 V DC ±15 %
Internal resistance 18 Ω
Allowable current 24 mA max
OFF-state leak current 100 μA max.
Short-circuit protection
function
Yes
Minimum OFF/ON time In time proportional cycle shorter than 10 s: 1 ms
In time proportional cycle of 10 s or longer: 250ms
Current output
Output type 0–20 mA DC or 4–20 mA DC
Allowable load resistance 600 Ω max.
Output accuracy ±0.3 % FS
However, ±1 % FS at 0–1 mA
z
Event relay (EV1–3) (optional)
Item Description
Number of outputs 3 (for models with 3 EV outputs)
2 (for models with 2 EV outputs with independent
contacts)
Contact configuration 1a (SPST)
Contact rating 250 V AC / 30 V DC, 2 A (resistive load)
Service life 100,000 cycles or more
Minimum switching specifications 5 V, 10 mA (reference value)
z
Loader communication
Item Description
Cables Dedicated USB loader cable (included with model
SLP-C1FJA0)
