Chapter 5. Functions
5 - 5 SP
The following is a functional block diagram for the SP. 5 - 6 Step operation (p.5-38) (for step operation)
LSP system group
(Setup bank: C30)
For one LSP group For two or more LSP groups
YesNo
LSP1
(SP bank: SP1)
LSP group selection in DI assignment bank
(DI assignment bank: dI1.1 to dI5.1)
LSP1–8
(SP bank: SP1 - SP8)
LSP group No.
(Operation settings: LSP No.)
Present LSP
SP ramp unit (Setup bank: C32)
SP up and down ramps (Parameter bank: SPU, SPd)
SP ramp enabling/disabling setting in the DI assignment bank
(DI assignment bank: dI1.1 to dI8.1)
SP low and high limits
(Setup bank: C07, C08)
SP
DI logical function
(DI assignment bank)
Note
• A local set point (LSP) is a set point stored in this device.
A set point given by an external analog input is called a remote set point (RSP) .
This device does not provide an RSP function.
To Next Page
