1. When you see the adjustment screen for the cyclic directions move the stick(s)
for aileron and elevator on the radio and check whether the swashplate is moved
correctly on the helicopter.
(Note for beginners: the swashplate must follow the stick movement, so pushing elevator
forward will tilt the swashplate forwards, adding aileron to the right will move the swash
to the right and so on.)
If the stick is moving the swashplate into the wrong direction use the reverse
function of your transmitter and reverse the aileron and/or elevator channel in the
transmitter to set stick control direction correctly.
2. Now adjust the internal control direction of the MICROBEAST PLUS gyro: When
you push elevator forwards, the Status LED must light up or flash in blue color and you
should see the label forwards getting blue as well. When you pull elevator backwards
, the Status LED must light up or flash in red color and you should see the label
backwards getting red as well. When you move aileron to the right, the Status LED
must light up or flash in blue color. When you move aileron to the left, the Status LED
must light up or flash in red color. When the display is inverted (red = right or
forwards and blue = left or backwards) reverse the display (internal control
direction) by choosing one of the four buttons below the direction label.
3. When the stick is not moving far enough, you will see the message ”Increase!” In this
case increase the servo throw/endpoint of the aileron or elevator channel in the
transmitter just as far so that the Status LED changes from flashing to solid
when the stick reaches the end position and the label in the software changes
to ”OK”. (Note: Do not increase the endpoints too much in the transmitter. We need an
exact match of full stick position and internal end position. So the Status LED should just
change from flashing to solid when reaching the end position.)
Always set servo direction in the transmitter first, then check the display on the
MICROBEAST PLUS or in the software and change the internal control direction if
