63 Setup with StudioXm
When the servo trim screen appears, for your reference the servos will briefly move up and
down once one after another in the given order CH1 to CH3 (CH7) so you can identify
them easily. Trim each servo using the + and - buttons so that the servo horn forms an
exact 90 degrees angle with the linkage rod. Then make the mechanical adjustment for the
linkages as described above if necessary.
