94 GOVERNOR MENU F, G & H -
Main gear ratio
This page is a translated version
1
of the page Manuals:MBPlusFblV52:Governormenu F
2
and the translation is 100% complete.
The Governor of MICROBEAST PLUS in general calculates with the rotor head speed of
the helicopter. So as shown at the transmitter setup step of GOVERNOR MENU you can
preset the desired head speed very easily and MICROBEAST PLUS will try to maintain
this headspeed as close as possible. Thus the detected rotation speed of the motor can be
converted into rotor head speed, you must specify the main gear ratio of the helicopter.
The gear ratio should be specified in the instruction manual for your helicopter.
Especially with electric models it will vary depending on the motor pinion used. For
helicopters with a single-stage gear drive the reduction can be calculated by dividing
the number of pinion teeth from the main gear tooth count.
Example: Shape S8 - Main gear tooth count 130 teeth / 15 tooth pinion. Gear ratio
apprx. 8.65:1. F - Status-LED purple flashing, G - Status-LED red, H - Status-LED
purple.
