1. When you see the adjustment screen for the collective pitch move the thrust stick
up and down and check whether the pitch is changing direction correctly. If not
already done at SETUP MENU point I, use the reverse function for the pitch chan-
nel in the transmitter to reverse direction of pitch movement in case it is wrong.
2. Afterwards check the Status LED color and display in the app: on positive pitch the
Status LED must be blue, on negative pitch it must light in red color. In case the
display is inverted (red = positive and blue = negative), reverse the internal
pitch direction of MICROBEAST PLUS by changing the direction in the app.
3. If the stick is not moving far enough, you will see the message ”Increase!”. In this case
increase the servo throw/endpoint of the thrust channel in the transmitter for
each direction just as far so that the Status LED changes from flashing to solid
and the label changes to ”OK” in the software when the stick reaches the end
positions. (Note: Do not increase the endpoints too much in the transmitter. We need an
exact match of full stick position and stick end position. So the Status LED should just
change from flashing to solid when reaching the end position.)
4. Finally adjust the maximum collective pitch when the thrust stick is at full deflection
for each direction using the + and - buttons in the app.
Always set the servo direction in the transmitter first, then check the display on the
MICROBEAST PLUS and change the internal control direction if it does not match
the real direction. Do not change the internal direction in order to change the
servo direction! This is only used for telling the system in which direction
is up and down. Be very conscientious when doing this setup step as wrong direction
will cause loss of control during rescue bailout and poor performance in general!
