29 Basic setup with StudioXm
When StudioXm is started and your MICROBEAST PLUS is connected to StudioXm
choose Basic heli setup from the device overview page to enter the setup wizard, which
will lead through the basic setup procedure of the SETUP MENU (note that the menu is
only accessible after all settings have been loaded from the device and when the device is
in operation mode! See general informations about StudioXm
1
if you need further instruc-
tions). The options you see here are basically similar to the SETUP MENU points A to M
you can change directly at the device, but there might be little differences because of the
different nature of the interactive setup. The adjustment is basically done using the buttons
or dials in the app, sometimes interaction with your transmitter is necessary. Click Next
at the bottom of each setup step to skip to the following Menu Point. From the dropdown
list at the top also you can directly access specific setup items if necessary, but for the first
time setup it is recommended to proceed step-by-step beginning at Device Orientation and
ending with Cyclic directions. Adjustment procedure in short words is described at each
step. If necessary refer to this manual if you need further assistance. When the setup is
finished click the Home button in the top left corner to get back to the overview screen
or disconnect the device and deactivate the BLE2SYS module by clicking the Disconnect
button in the top right corner when adjustment is finished completely.
Note: When you cannot access the menu options because the system does not finish
initialization sequence, make sure the radio system is powered up and bound correctly and
proceed with RECEIVER MENU adjustment
2
first, if necessary!
Always disconnect your BLE2SYS from the app when you attempt to
fly in order to deactivate the module or disconnect it physically from your
MICROBEAST PLUS. When the module is active this can cause interference with
your radio system as the BLE2SYS is also sending on the 2.4GHz band!
Also make sure MICROBEAST PLUS is in operation mode! When it is still
in one of the adjustment menus the gyro control and the stick controls may be disabled
and you will not be able to fully control your helicopter!
1
https://wiki.beastx.com/./index.php/StudioXm/en
2
https://wiki.beastx.com/./index.php/Manuals:MBPlusFblV52:ReceiverType/en
