Administration: Discovery
Configuring LLDP
155 Cisco 500 Series Stackable Managed Switch Administration Guide
9
STEP 2 The message at the top of the page indicates whether the generation of the LLDP
MED Network Policy for the voice application is automatic or not (see LLDP
Overview). Click on the link to change the mode.
STEP 3 To associate additional LLDP MED TLV and/or one or more user-defined LLDP
MED Network Policies to a port, select it, and click Edit.
STEP 4 Enter the parameters:
• Interface—Select the interface to configure.
• LLDP MED Status—Enable/disable LLDP MED on this port.
• SNMP Notification—Select whether SNMP notification is sent on a per-port
basis when an end station that supports MED is discovered; for example a
SNMP managing system, when there is a topology change.
• Selected Optional TLVs—Select the TLVs that can be published by the
device by moving them from the Available Optional TLVs list to the Selected
Optional TLVs list.
• Available Network Policies—Select the LLDP MED policies to be published
by LLDP by moving them from the Available Network Policies list to the
Selected Network Policies list. These were created in the LLDP MED
Network Policy page
.
To include one or more user-defined network polices
in the advertisement, you must also select Network Policy from the
Available Optional TLVs.
NOTE The following fields must be entered in hexadecimal characters in the
exact data format that is defined in the LLDP-MED standard (ANSI-TIA-
1057_final_for_publication.pdf):
- Location Coordinate—Enter the coordinate location to be published by
LLDP.
- Location Civic Address—Enter the civic address to be published by
LLDP.
- Location ECS ELIN—Enter the Emergency Call Service (ECS) ELIN
location to be published by LLDP.
STEP 5 Click Apply. The LLDP MED port settings are written to the Running Configuration
file.
