Cisco 500 Series Administration Guide

Port Management
Configuring Ports
183 Cisco 500 Series Stackable Managed Switch Administration Guide
10
• Automatic Recovery Interval—Specify the time delay for automatic error
recovery, if enabled, after a port is shutdown
Automatic ErrDisable Recovery
• Port Security—Select to enable automatic error recovery when the port
has been shut down for port security violations
• 802.1x Single Host Violation—Select to enable automatic error recovery
when the port has been shut down by 802.1x.
• ACL Deny—Select to enable automatic error recovery mechanism by an
ACL action.
• STP BPDU Guard—Select to enable automatic error recovery mechanism
when the port has been shut down by STP BPDU guard.
• STP Loopback Guard— Enable automatic recovery when the port has been
shut down by STP Loopback Guard.
• UDLD—Select to enable automatic error recovery mechanism for the UDLD
shutdown state.
• Loopback Detection—Select to enable error recovery mechanism for ports
shut down by loopback detection.
STEP 3 Click Apply to update the global setting.
To manually reactivate a port:
STEP 1 Click Port Management > Error Recovery Settings.
The list of inactivated interfaces along with their Suspension Reason is displayed.
STEP 2 Select the interface to be reactivated.
STEP 3 Click Reactivate.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
