Port Management
Configuring Green Ethernet
Cisco 500 Series Stackable Managed Switch Administration Guide 198
10
Default Configuration
By default, 802.3az EEE and EEE LLDP are enabled globally and per port.
Interactions Between Features
The following describe 802.3az EEE interactions with other features:
• If auto-negotiation is not enabled on the port, the 802.3az EEE operational
status is disabled. The exception to this rule is that if the link speed is 1
gigabyte, EEE still be enabled even though Auto-Negotiation is disabled.
• If 802.3az EEE is enabled and the port is going Up, it commences to work
immediately in accordance with the maximum wake time value of the port.
• On the GUI, the EEE field for the port is not available when the Short Reach
Mode option on the port is checked.
• If the port speed on the GE port is changed to 10Mbit, 802.3az EEE is
disabled. This is supported in GE models only.
802.3az EEE Configuration Workflow
This section describes how to configure the 802.3az EEE feature and view its
counters.
STEP 1 Ensure that auto-negotiation is enabled on the port by opening the Port
Management > Port Settings page.
a. Select a port and open the Edit Port Setting page.
b. Select Auto Negotiation field to ensure that it is Enabled.
STEP 2 Ensure that 802.3 Energy Efficient Ethernet (EEE) is globally enabled in the Port
Management > Green Ethernet > Properties page (it is enabled by default). This
page also displays how much energy has been saved.
STEP 3 Ensure that 802.3az EEE is enabled on a port by opening the Green Ethernet > Port
Settings page.
a. Select a port, open the Edit Port Setting page.
b. Check the 802.3 Energy Efficient Ethernet (EEE) mode on the port (it is enabled
by default).
c. Select whether to enable or disable advertisement of 802.3az EEE capabilities
through LLDP in 802.3 Energy Efficient Ethernet (EEE) LLDP (it is enabled by
default).
