Cisco 500 Series Administration Guide

Smartport
Auto Smartport
221 Cisco 500 Series Stackable Managed Switch Administration Guide
12
SR Bridge 0x04 Ignore
Switch 0x08 Switch
Host 0x10 Host
IGMP conditional filtering 0x20 Ignore
Repeater 0x40 Ignore
VoIP Phone 0x80 ip_phone
Remotely-Managed Device 0x100 Ignore
CAST Phone Port 0x200 Ignore
Two-Port MAC Relay 0x400 Ignore
LLDP Capabilities Mapping to Smartport Type
Capability Name LLDP Bit Smartport Type
Other 1 Ignore
Repeater IETF RFC 2108 2 Ignore
MAC Bridge IEEE Std. 802.1D 3 Switch
WLAN Access Point IEEE Std. 802.11
MIB
4Wireless Access
Point
Router IETF RFC 1812 5 Router
Telephone IETF RFC 4293 6 ip_phone
DOCSIS cable device IETF RFC 4639
and IETF RFC 4546
7Ignore
Station Only IETF RFC 4293 8 Host
C-VLAN Component of a VLAN Bridge
IEEE Std. 802.1Q
9Switch
S-VLAN Component of a VLAN Bridge
IEEE Std. 802.1Q
10 Switch
Two-port MAC Relay (TPMR) IEEE Std.
802.1Q
11 Ignore
CDP Capabilities Mapping to Smartport Type (Continued)
Capability Name CDP Bit Smartport Type

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
