PoE Priority Example:
Given: A 48 port device is supplying a total of 375 watts.
The administrator configures all ports to allocate up to 30 watts. This results in 48
times 30 ports equaling 1440 watts, which is too much. The device cannot provide
enough power to each port, so it provides power according to the priority.
The administrator sets the priority for each port, allocating how much power it can
be given.
These priorities are entered in the PoE Settings page.
See Device Models for a description of the device models that support PoE and
the maximum power that can be allocated to PoE ports.
To configure PoE port settings:
STEP 1 Click Port Management > PoE > Settings.The list of fields below is for Port Limit
Power Mode. The fields are slightly different if the Power Mode is Class Limit.
STEP 2 Select a port and click Edit.
STEP 3 Enter the value for the following field:
• Interface—Select the port to configure.
• PoE Administrative Status—Enable or disable PoE on the port.
• Time Range—Select to enabled PoE on the port.
• Time Range Name—If Time Range has been enabled, select the time range
to be used. Time ranges are defined in the Time Range page.
• Power Priority Level—Select the port priority: low, high, or critical, for use
when the power supply is low. For example, if the power supply is running at
99% usage and port 1 is prioritized as high, but port 3 is prioritized as low,
port 1 receives power and port 3 might be denied power.
• Administrative Power Allocation—This field appears only if the Power Mode
set in the PoE Properties page is Port Limit. If the Power mode is Power Limit,
enter the power in milliwatts allocated to the port.
• Max Power Allocation—This field appears only if the Power Mode set in the
PoE Properties page is Power Limit. Displays the maximum amount of power
permitted on this port.
• Power Consumption—Displays the amount of power in milliwatts assigned
to the powered device connected to the selected interface.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
