VLAN Management

Overview

Cisco 500 Series Stackable Managed Switch Administration Guide 258

The following describes server/router traffic (reply to host).

Figure 2 Server/Router Traffic to Hosts

Isolated 1 Isolated 2

Server

Community 1 Community 1

Promiscous Promiscous

Isolated Isolated Community Community Community

Community 1

Primary VLAN
