VLAN Management
Regular VLANs
263 Cisco 500 Series Stackable Managed Switch Administration Guide
14
• Default VLAN ID After Reboot—Enter a new VLAN ID to replace the default
VLAN ID after reboot.
STEP 3 Click Apply.
STEP 4 Click Save (in the upper-right corner of the window) and save the Running
Configuration to the Startup Configuration.
The Default VLAN ID After Reset becomes the Current Default VLAN ID after
you reboot the device.
VLAN Settings - Creating VLANs
You can create a VLAN, but this has no effect until the VLAN is attached to at least
one port, either manually or dynamically. Ports must always belong to one or more
VLANs.
Each VLAN must be configured with a unique VID with a value from 1 to 4094. The
device reserves VID 4095 as the Discard VLAN. All packets classified to the
Discard VLAN are discarded at ingress, and are not forwarded to a port.
To c r e a t e a V L A N :
STEP 1 Click VLAN Management > VLAN Settings.
Information is displayed for all defined VLANs. The fields are defined below under
the Add page. The following field is not on the Add page.
• Originators—How the VLAN was created:
- GVRP—VLAN was dynamically created through Generic VLAN
Registration Protocol (GVRP).
- Static—VLAN is user-defined.
- Default—VLAN is the default VLAN.
STEP 2 Click Add to add one or more new VLANs.
The page enables the creation of either a single VLAN or a range of VLANs.
STEP 3 To create a single VLAN, select the VLAN radio button, enter the VLAN ID, and
optionally the VLAN Name.
