Cisco 500 Series Administration Guide

VLAN Management
VLAN Groups
273 Cisco 500 Series Stackable Managed Switch Administration Guide
14
a. Assign the VLAN group to a VLAN (using Mac-Based Groups to VLAN page).
The interfaces must be in General mode.
b. If the interface does not belong to the VLAN, manually assign it to the VLAN
using the Port to VLAN page.
MAC-based VLAN Groups
See Table 6 for a description of the availability of this feature.
To assign a MAC address to a VLAN Group:
STEP 1 Click VLAN Management > VLAN Groups > MAC-Based Groups.
STEP 2 Click Add.
STEP 3 Enter the values for the following fields:
• MAC Address—Enter a MAC address to be assigned to a VLAN group.
NOTE This MAC address cannot be assigned to any other VLAN group.
• Prefix Mask—Enter one of the following:
- Host—Source host of the MAC address
- Length—Prefix of the MAC address
• Group ID—Enter a user-created VLAN group ID number.
STEP 4 Click Apply. The MAC address is assigned to a VLAN group.
VLAN Group to VLAN Per Interface
See Table 6 for a description of the availability of this feature.
Ports/LAGs must be in General mode.
To assign a MAC-based VLAN group to a VLAN on an interface:
STEP 1 Click VLAN Management > VLAN Groups > MAC-Based Groups to VLAN.
STEP 2 Click Add.
STEP 3 Enter the values for the following fields:
• Group Type—Displays that the group is MAC-Based.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
