Multicast
MAC Group Address
321 Cisco 500 Series Managed Switch Administration Guide
17
data is acquired either dynamically through IGMP/MLD snooping or statically
by manual entry.
• Add or delete static entries to the MFDB that provide static forwarding
information, based on MAC destination addresses.
• Display a list of all ports/LAGs that are a member of each VLAN ID and MAC
address group, and enter whether traffic is forwarded to it or not.
To define and view MAC Multicast groups:
STEP 1 Click Multicast > MAC Group Address.
STEP 2 Enter the Filter parameters.
• VLAN ID Equals To—Set the VLAN ID of the group to be displayed.
• MAC Group Address Equals To—Set the MAC address of the Multicast
group to be displayed. If no MAC Group Address is specified, the page
contains all the MAC Group Addresses from the selected VLAN.
STEP 3 Click Go, and the MAC Multicast group addresses are displayed in the lower
block.
Entries that were created both in this page and in the IP Multicast Group Address
page are displayed. For those created in the IP Multicast Group Address page, the
IP addresses are converted to MAC addresses.
STEP 4 Click Add to add a static MAC Group Address.
STEP 5 Enter the parameters.
• VLAN ID—Defines the VLAN ID of the new Multicast group.
• MAC Group Address—Defines the MAC address of the new Multicast
group.
STEP 6 Click Apply, the MAC Multicast group is saved to the Running Configuration file.
To configure and display the registration for the interfaces within the group, select
an address, and click Details.
The page displays:
• VLAN ID—The VLAN ID of the Multicast group.
• MAC Group Address—The MAC address of the group.
STEP 7 Select either port or LAG from the Filter: Interface Type menu.
