Cisco 500 Series Administration Guide

Multicast
Unregistered Multicast
339 Cisco 500 Series Managed Switch Administration Guide
17
Unregistered Multicast frames are usually forwarded to all ports on the VLAN.
You can select a port to receive or reject (filter) unregistered Multicast streams.
The configuration is valid for any VLAN of which the port is a member (or will be a
member).
To define unregistered Multicast settings:
STEP 1 Click Multicast > Unregistered Multicast.
STEP 2 Select the Interface Type equals to— To view either ports or LAGs.
STEP 3 Click Go.
STEP 4 Define the following:
• Port/LAG—Displays the port or LAG ID.
• Displays the forwarding status of the selected interface. The possible values
are:
- Forwarding—Enables forwarding of unregistered Multicast frames to the
selected interface.
- Filtering—Enables filtering (rejecting) of unregistered Multicast frames to
the selected interface.
STEP 5 Click Apply. The settings are saved, and the Running Configuration file is updated.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
