IP Configuration
IPv4 Management and Interfaces
345 Cisco 500 Series Managed Switch Administration Guide
18
Defining an IPv4 Interface in Layer 2 System Mode
This section is not relevant for the SG500X, ESW2-550X or SG500XG device.
To manage the device by using the web-based configuration utility, the IPv4
device management IP address must be defined and known. The device IP
address can be manually configured or automatically received from a DHCP
server.
To configure the IPv4 device IP address:
STEP 1 Click Administration > Management Interface > IPv4 Interface.
STEP 2 Enter values for the following fields:
• Management VLAN—Select the Management VLAN used to access the
device through telnet or the Web GUI. VLAN1 is the default Management
VLAN.
• IP Address Type—Select one of the following options:
-
Dynamic
—Discover the IP address using DHCP from the management
VLAN.
-
Static
—Manually define a static IP address.
NOTE DHCP Option 12 (Host Name option) is supported when the device is
a DHCP client. If DHCP Option 12 is received from a DHCP server, it is saved
as the server’s host name. DHCP option 12 will not be requested by the
device. The DHCP server must be configured to send option 12, regardless
of what is requested in order to make use of this feature.
To configure a static IP address, configure the following fields.
• IP Address—Enter the IP address, and configure one of the following Mask
fields:
- Network Mask—Select and enter the IP address mask.
- Prefix Length—Select and enter the length of the IPv4 address prefix.
• Loopback Interface—Select to enable the configuration of a loopback
interface (see Loopback Interface).
• Loopback IP Address—Enter the IPv4 address of the loopback interface.
