Cisco 500 Series Administration Guide

Security: IPv6 First Hop Security
IPv6 First Hop Security Overview
513 Cisco 500 Series Stackable Managed Switch Administration Guide
23
IPv6 First Hop Security Components
IPv6 First Hop Security includes the following features:
• IPv6 First Hop Security Common
• RA Guard
• ND Inspection
• Neighbor Binding Integrity
• DHCPv6 Guard
• IPv6 Source Guard
These components can be enabled or disabled on VLANs.
There are two empty, pre-defined policies per each feature with the following
names: vlan_default and port_default. The first one is attached to each VLAN that
is not attached to a user-defined policy and the second one is connected to each
interface and VLAN that is not attached to a user-defined policy. These policies
cannot be attached explicitly by the user. See Policies, Global Parameters and
System Defaults.
IPv6 First Hop Security Pipe
If IPv6 First Hop Security is enabled on a VLAN, the switch traps the following
messages:
• Router Advertisement (RA) messages
• Router Solicitation (RS) messages
NA message Neighbor Advertisement message
NDP Neighbor Discovery Protocol
NS message Neighbor Solicitation message
RA message Router Advertisement message
RS message Router Solicitation message
SAVI Source Address Validation Improvement
Name Description

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
