Security: IPv6 First Hop Security
Configuring IPv6 First Hop Security through Web GUI
Cisco 500 Series Stackable Managed Switch Administration Guide 540
23
Neighbor Binding Table
To view entries in the Neighbor Binding table:
STEP 1 Click Security > IPv6 First Hop Security > Neighbor Binding Table
STEP 2 Select one of the following clear table options:
• Static Only—Clear all static entries in the table.
• Dynamic Only—Clear all dynamic entries in the table.
• All Dynamic & Static —Clear all dynamic and static entries in the table.
Enter the following fields:
• VLAN ID—VLAN ID of the entry.
• IPv6 Address—Source IPv6 address of the entry.
• Interface Name— Port on which packet is received.
• MAC Address— Neighbor MAC address of the packet.
• Origin—Protocol that added the IPv6 address (only available for dynamic
entries):
- Static—Added manually.
- NDP—Learnt from Neighbor Discovery Protocol messages.
- DHCP—Learnt from DHCPv6 protocol messages.
• State—State of the entry:
- Ten t at i v e—The new host IPv6 address is under validation. Since its
lifetime is less than 1 sec its expiration time is not displayed.
- Valid—The host IPv6 address was bound.
• Expiry Time (Sec.)—Remaining time in seconds until the entry will be
removed, if it is not confirmed.
• TCAM Overflow—Entries marked as No have not been added to the TCAM
because TCAM overflow
