Cisco CRS Configuration Guide

SUMMARY STEPS
1.
configure
2.
mpls traffic-eng
3.
interface type interface-path-id
4.
lmp data-link adjacency
5.
remote switching-capability {fsc | lsc | psc1}
6.
remote interface-id unnum value
7.
remote node-id node-id
8.
neighbor name
9.
remote node-id address
10.
Use the commit or end command.
11.
show mpls lmp
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters MPLS-TE configuration mode.mpls traffic-eng
Example:
RP/0/RP0/CPU0:router(config)# mpls traffic-eng
Step 2
Enters MPLS-TE interface configuration mode and enables
TE on a particular interface on the originating node.
interface type interface-path-id
Example:
RP/0/RP0/CPU0:router(config-mpls-te)# interface
Step 3
POS0/6/0/0
Configures LMP neighbor remote TE links.lmp data-link adjacency
Example:
RP/0/RP0/CPU0:router(config-mpls-te-if)# lmp
Step 4
data-link adjacency
Configures the remote LMP MPLS-TE interface switching
capability.
remote switching-capability {fsc | lsc | psc1}
Example:
RP/0/RP0/CPU0:router(config-mpls-te-if-adj)#
Step 5
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
255
Implementing MPLS Traffic Engineering
Configuring GMPLS
